RONGSHENG 13-5/8" Bonnet Seal Blowout Preventer Equipment 5000 PSI

Certification
China Shaanxi FORUS Petroleum Machinery Equipment Co., Ltd certification
China Shaanxi FORUS Petroleum Machinery Equipment Co., Ltd certification
I'm Online Chat Now

RONGSHENG 13-5/8" Bonnet Seal Blowout Preventer Equipment 5000 PSI

RONGSHENG 13-5/8" Bonnet Seal Blowout Preventer Equipment 5000 PSI
RONGSHENG 13-5/8" Bonnet Seal Blowout Preventer Equipment 5000 PSI
RONGSHENG 13-5/8" Bonnet Seal Blowout Preventer Equipment 5000 PSI RONGSHENG 13-5/8" Bonnet Seal Blowout Preventer Equipment 5000 PSI RONGSHENG 13-5/8" Bonnet Seal Blowout Preventer Equipment 5000 PSI RONGSHENG 13-5/8" Bonnet Seal Blowout Preventer Equipment 5000 PSI

Large Image :  RONGSHENG 13-5/8" Bonnet Seal Blowout Preventer Equipment 5000 PSI

Product Details:
Place of Origin: China
Brand Name: RONGSHENG
Certification: API16A
Model Number: 13-5/8"
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Packaging Details: Wooden Box
Delivery Time: 15days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 sets per month

RONGSHENG 13-5/8" Bonnet Seal Blowout Preventer Equipment 5000 PSI

Description
Product Name: Bonnet Seal Pressure: 5000PSI
Material: Rubber/HNBR Application: Drilling BOP

RONGSHENG 13-5/8" Bonnet Seal Blowout Preventer Equipment 5000 PSI



All metallic materials that come in contact with well fluids shall meet the requirements of NACE MR0175/ISO 15156 for sour service.



Product of Blowout Preventer Equipment



Upper housing and the body have two connection forms as connection by bolts and connection by claw chuck.



Annular BOP with spherical rubber is composed of five parts as upper housing, body,piston,spherical rubber and anti-dust ring.



The dynamic seal of annular BOP adopts the sealing ring of lip structure, which reduces the wearing of sealing ring to the maximum, and the



sealing is reliable, the rubber is not easy to fold back, and there is the effect of funnel, and the well pressure has the function of assisting sealing , etc.



Parameter

Model Bore(mm) Working Pressure(Mpa/psi) Close Volume(L) Open Volume(L) Dimension(mm) Total WeightForreference)(kg) Product Code
A B C D E F
FH18-21 179.4 21/3000 21 15 745 769 141 309 37 225 1433 RS11827.00
FH18-35 35/5000 21 15 745 797 169 309 31 231 1520 RS11168.00
FH23-21 228.6 21/3000 34 22.8 902 838 128 494 48 260 2398 RS11143.00
FH23-35 35/5000 42 33 1016 860 110 500 72 262 2986 F9303.00
FH28-21 279.4 21/3000 50 39 1014 870 152 529 52 29 2950 RS11150.00
FH28-35 35/5000 6 72 1146 1110 242 676 74 313 4675 RS11135.00
FH35-21 346.1 21/3000 94 69 1271 1105 170 470 80 345 5738 RS11186.00
FH35-21 35/5000 94 69 1271 1150 200 670 85 340 6415 F35.00
FH48-35 425.3 35/5000 220 171 1683 1558 296 1410 428 534 16000 RS1184.00
FH53-21 527 21/3000 173 110 1375 1293 260 569 74 414 6994 RS111100.00
FH54-35 539.7 35/5000 241 181 2240 1718 315 1201 140 564 20230 RS11801.00



Feature



Model: it can meet the requirement of drilling, under-balance drilling, workover, non-kill operation etc.


Complete size:Bore is 4 1/16” to 29 1/2”, pressure is 500psi to 15000psi.


Various function:it matched with shear ram, variable ram, eccentric ram etc.They can be used in specialized condition. Series shear ram can



shear 5” S-135 drilling pipe, realize the full sealing and ensure safety.


The anti-H2S performance meet the NACE MR-01-75 standard, suitable for developing the deep well, high pressure well, high H2S well.
